Importantly, there is an additional factory fitted option to add a sub-spindle (+S). This offers a spindle speed of 4,500 rpm, with a 5.5 kW power motor generating a torque of 24 Nm.The chuck diameter is 165 mm.
The main spindle on the machine features 15 kW power and a torque of 110 Nm. It accommodates bars up to 65 mm diameter and offers improved rigidity via a 26% increase in curvic coupling.
Milling power is 5.5 kW (24 Nm), while Y-axis travel is ±41 mm.
