Intelligent functions with hyperCAD 2009.1

Intelligent functions include surface feedback (AutoPatching) to STL meshes, surface repair, the generation of parting lines and draft geometry and shrinkage compensation. HyperCAD SMART OBJECT technology eliminates some routine time-consuming tasks. Using the function for completing surfaces, users can continuously or tangentially extend or close off open areas with fill surfaces, quickly add in missing areas, and link any surface to other components. SMART OBJECT also allows users to save and reuse, standard and custom-defined intelligent design elements and concepts. When applied, these adjust to the different topologies and geometric data, automatically. The hyperReshape function now allows STL data to be processed or modified. This function makes it possible to close holes, reduce STL networks and create boundaries. Subcontractors will benefit from the hybrid processing of surfaces, solids and STL data, that facilitates data exchange and cuts the number of CAD systems required. The hyperCAD 2009.1 features solutions for tool and mould construction, with optional extras for electrode production or for controlling wire EDM. Another new feature is the option to create templates for project-specific CAD environments. This results in enormous time savings for the user, as project-specific settings such as layer, title block or colours are predefined when the program starts up. The version comparison function checks the design for differences and displays any that are found using colour coding. This allows the different stages of construction to be easily checked and analysed when versions have been changed.
