Increased 5-axis support with Edgecam 2009 R1

Edgecam 2009 R1 extends its already extensive support for popular 5-axis machines with the introduction of the nutated head/rotary table configuration (pictured). Historically, the programming of 5-axis components has been among the most difficult tasks in CAM programming. “In the 5-axis environment, Edgecam 2009 R1 is very easy to use and, by default, creates a safe toolpath that will produce a finished part,” explains Planit’s chief technology officer, Russell Franks. The flexible nature of 5-axis machining means there is always a number of different ways the machine tool can move to produce the same cut. Confidence in the toolpath is paramount in 5-axis, and in Edgecam this is achieved through reliable creation and visualisation. Enhanced capabilities within Edgecam 2009 R1 enable a full 5-axis machine model to be visualised, along with component geometry and toolpath.
