Edgecam 2011 R1 sees multiple improvements
1 min read
Edgecam 2011 R1 sees the package's extensive range of milling features for roughing components now included in one special 'composite' feature that optimises roughing and reduces tool changes. The new composite feature collects all the features on the part, allowing them to be easily roughed in one operation.
Instead of having to machine individual pockets and features, it now means the user gets a much more complete roughing cycle in one go from Edgecam's Strategy Manager. It optimises the tool path by reducing the amount of instructions needed, says the company.
Additional improvements see the machining simulator's collision checking function improved. Users can now check the turret, its holders and adjacent tools in the turret.
Another improvement on the rough turning cycle is swarf clearance. With long, deep boring, material can get jammed inside the bore and the machine has to be stopped to clear it out. The new feature enables the operator to retract the tool automatically, after a defined amount of cuts, and stop the machine, enabling it to be cleared before continuing with the same cycle. This greatly improves toolpath efficiency.
Improvements in the performance of the machining engine give faster toolpath creation times – in particular the roughing cycle when moving between different areas of the machine parts.
Another major improvement in Edgecam 2011 R1 is the ability to merge tool stores, including tool, material and job information.
Edgecam 2011 R1 also contains many small but important, 'Ease of Use' improvements, which have been asked for by customers. These include new default schemes, improvements to toolpath display, improved sequence error checking, and more picture-based operations.
