Wallwork Cast Alloys solves heat treatment process castings issue for Independent Forgings and Alloys

Independent Forgings and Alloys was seeing cracking in the stainless steel base grids and pan casings used to support forgings during the heat treatment process. Independent Forgings specialise in open die forgings in carbon steel, stainless steel and alloys of nickel and titanium. These go to OEMs in aerospace, oil and gas, nuclear, defence, power and other demanding industries. The Wallwork programme will modify patterns, review alloy choice and the casting process to produce longer life castings to withstand the rigours of cyclical heating and cooling during heat treatment. This in turn will reduce energy needs, improve cycle times, and contribute to lean production and quality goals. The original supplier was unwilling to address the issue by modifying the design or material and so Wallwork were approached for an alternative. "We examined the failed grids and casings and concluded that we could offer extended life by a design modification to the pattern and using a 55/18 nickel/chrome alloy with a higher temperature tolerance," explains Wallwork director Peter Carpenter. "As a heat treatment specialist producing furnace furniture for our own factories, our working experience is part of the design process," he added. "We understand the need for high strength with low thermal mass – designs that optimise component packing density, but still allow circulation space for even heating and effective quenching. Castings that retain their shape and have a good working life are vital to profitability." Pawel Grzesiakowski, heat treatment manager at Independent Forgings and Alloys adds: "We apply various heat treatment processes, such as hardening, tempering, solution treatment, ageing and stress relieving, in temperatures ranging from 420 to 1,230 °C. All processes follow stringent quality control procedures to ensure that we meet each customer's metallurgical requirements. The Wallwork engineer had an immediate understanding of how we use the grids and pan casings. After examination of the failed units, he was able to tell us how an improved design would add strength in the vulnerable areas with a reduction in weight and an improvement in the thermal performance of the casting." Mr Carpenter observes: "Modern techniques can produce castings that are lighter and stronger. Less thermal mass means that the process meets its optimal temperature more quickly – reducing cycle times and so improving process productivity, reducing per component processing cost and overall energy consumption and carbon release. Extending the life of the furnace furniture also improves efficiency because less capital is tied up in the supply chain for jigs and castings". Wallwork Cast Alloys carry standard patterns in stock for use with Ipsen, Wild Barfield, Seco Warwick, Wellman and other heat treatment furnaces. Furnace furniture is most commonly produced in a 37/18 nickel/chrome iron alloy that retains its strength to 1,050 °C. The company also produce furnace furniture up to 80/20 nickel/chrome castings that can operate up to 1,250 °C. In addition to standard and modified patterns, the company offers a custom 3D design and pattern making service to address a client's specific production goals. Typical turnaround for castings is six to eight weeks where pattern making and customisation is required. This may be less where the pattern is already held and no modification is needed. The company has the flexibility to provide an express service to meet special circumstances
