Ficep exhibit steel processing machines at MACH 2010

The Gemini 254 PG is a flexible multi-function system for profile cutting, drilling, machining and scribing, with a bevelling capability, using either HT2000 or HPR260 Hypertherm plasma systems. This compact footprint machine can produce flat metal parts from plate, 5 mm to 75 mm thick, in one set-up. The 601 DE Excalibur 6 outperforms manual methods of drilling for the smaller fabricator and can provide additional capacity for companies looking for a low cost solution to increase their productivity. This drilling line features a movable spindle that rapidly travels the entire length of the material and can drill a hole, up to 40 mm in diameter, every 5 seconds. The versatility of this CNC system makes it suited for flange drilling, web drilling, angles, plate detail and structural tubes, up to 610 mm high and 610 mm wide.
