Additional specifications are: a 30-tool toolchanger that can change tools in 1.6 seconds, with a chip-to-chip time of four seconds; rapid feed rates of 48 m/min in X and Y axes, plus 32 m/minin the Z direction; BBT-40 face-and-taper contact spindle; 18.5 kW, 12,000 rpm spindle; 840 by 500 mm, 500 kg capacity table.
Fanuc i-MF CNC control unit with 10.4-in monitor features, as does a spindle oil cooler to maintain performance and longevity. Additionally, the P76 offers: rigid taping; remote MPG; three-step warning light; levelling pads; auto power-off; and a screw-type swarf removal system.
Victor CNC can tailor the machine with optional extras that include a 40-tool ATC, coolant gun, automatic tool length measurement, auto part measuring and even a fourth- and fifth-axis interface.
For enhanced precision and meeting the needs of high speed machining, the P76 can be configured with linear scales, a 15,000rpm spindle, rotary tables, oil skimmer, automatic doors, spindle through-coolant, a Heidenhain TNC-620/640 CNC control and more.
