Vero announces major enhancements delivered by Visi 20 mould and die software

2 mins read

Major graphic enhancements have been incorporated into the latest release of Vero's mould and die software product, Visi 20. These include improved rendering, a programmable dynamic command widget and the ability to fast-view a file before opening to include pan and zoom functionality. In addition, CAD translators have been updated to support Solid Works and Solid Edge assemblies, and support for PTC Creo and JTopen B-rep entities.

CAD enhancements include the ability to assign constraints to geometrical bodies (Concentric, Parallel, Coincident, Distance, etc) providing the tools to simulate the real movement of tooling, such as the ability to check for collisions with slides, cams, lifters, etc. A re-designed feature manager and 3D boring chart creates and edits complex holes and pockets as well as recognising features directly from the 3D model or 2D drawing for automated annotation. Process workflow improvements include the ability to extract wireframe edges and also concatenate and simplify the extracted elements, remove knot points and split the geometry into correctly formatted curves based on angular deviation. Automating the process in this way significantly speeds up high quality surface creation when working with third-party data. Visi Progress developments include a tool building engine, improved unfolding and middle skin functionality for flanging and blanking operations. Other enhancements include a completely rewritten explode tool for 3D assemblies (with the ability to record the explode movements), improved standard component catalogues and continued collaboration with CADENAS. Visi Flow, for plastic flow analysis is now 64 bit compatible, and therefore capable of benefiting from additional hardware performance. Other developments include tools for the thermal analysis of conformal cooling. This process provides the ability to analyse 3D cooling circuits produced using rapid prototyping techniques and impossible to manufacture using traditional drilling/boring cycles. In addition, improvements to sequential moulding, gas assisted and over-moulding ensure mould makers benefit from the latest cutting edge technologies. Visi 20 represents another release with major CAM development. One innovation is the ability to distribute the toolpath computation onto different machines connected to the same private network. This technology uses 'distributed computing', where the computers interact with each other to achieve a common goal. A goal is divided into many tasks, each of which is solved by one computer connected to the network. The main advantages are that the combination of slave computers can produce a similar computing resource to a multi-processor super-computer and keep the master PC free from heavy calculations. Toolpath algorithm enhancements include a roughing strategy, improved auto rest machining, multi-axis side wall machining and multi-axis roughing. The Visi 20 roughing strategy massively reduces rapid moments, optimises stepover when using values above 50% of the tool diameter and propagates high speed transitions and 'corner pip' movements avoiding feed reduction while machining. Other CAM developments include improved collision control, a feature recognition engine, support for additional tooling forms (barrel cutters, convex tip cutters, radiused chamfer cutters and radiused dove cutter) and a 'dynamic incremental stock' (DIS) command that automatically creates the stock model from the uncut material of previous operations and automatically trims the toolpath to remove unnecessary movements and fresh air cuts. Wire EDM developments include the ability to auto-detect undercuts. When the offset is larger than the radius of an arc, the toolpath can self-intersect. The solid simulation has been enhanced to detect these conditions where the toolpath crosses and highlight these in the movement list. The user can optionally ignore these conditions or have the simulation automatically stop when they occur. Corner relief tools allow the addition of corner relief to all internal corners and external corners independently. It is usual for a user to want to apply these separately; for example, to add relief to a die-only internal corner. Finally, the technology database has been enhanced so the materials presented are filtered against the machine model as opposed to the machine family, and the available wire types are filtered against the material type.
