Time saving software enhancements for machining complex components

Version 9.6 of NCL multi-axis machining software is said to make the generation of complex tool paths faster than ever. New strategies are included for flow-line milling enabling the user to machine multiple surfaces in a single operation with the option of milling around avoidance surfaces. Feature recognition tactics have been added that allow circular interpolation records to be processed as a single arc motion rather than a series of linear motions. The ability to process as a single motion results in a much quicker simulation of circular records and a more accurate measurement of circular cuts. Improved tool displays have been added to the external library file including the shape of the cutter, shank and toolholder. These definitions give users more flexibility in defining the shape of the tool, including the individual shading for the cutter, shank and holder, individual tool shank and holder offsets, and the ability to define different classes of tools, such as mills, lathe bits, blades, routers, shanks and holders.
