Using multiple software systems to manage cutting tool data and toolholder assembly models is both time-consuming and error-prone. Current and future CGTech customers can enjoy seamless integration with the same technology that companies around the world depend on every day to enhance product development decision making and produce better products.
NX users can now click, connect and import files into Vericut directly from NX, saving time and eliminating problems.“Oftentimes, the most labour-intensive part of toolpath verification is modelling the various cutting tools and assemblies,” says Tony Shrewsbury CGTech Ltd, managing director. “This is especially true with the large, complex machining work common with NX users, where 30 to 40 tools in a single job is not unusual. Because we now connect directly to Teamcenter, it’s easy to search for individual tools within the PLM system or NX project files, and then read them into Vericut accordingly, either individually or as a group. It’s a huge timesaver.”
The Teamcenter integration works seamlessly with MRL (manufacturing resource library), explains Shrewsbury. Users won’t be tempted to model toolholder assemblies that are ‘close enough’ in an effort to save time, or be concerned about different models floating around outside the PLM system - versions are in control, and there is a commonality and standardisation for all of a shop’s cutting tools.
Also, Vericut customers migrating their CAM systems to NX and Teamcenter can use their existing models, importing them directly into Teamcenter, or download them from such sources as Tools United, Machining Cloud or the tool vendor’s website, thus creating a master library within the PLM system and one version of the truth.
“Siemens PLM Software is enthusiastic about the collaboration with CGTech. This agreement is another important step in the development of an integrated solution that will provide added value to our mutual customers,” says Corsin Buerer, head of production and quality products, Siemens PLM Software.
Shrewsbury agrees. “The Teamcenter and MRL connection was developed in response to numerous requests from shops wishing to streamline and secure the tool management process within a robust PLM system. Working with Siemens, we’ve accomplished that goal and further enhanced both of our products. This gives our Vericut customers - both existing and future - another way to improve shop operations, reduce risk to expensive machine tools, and instil a sense of confidence in programmers and machinists alike.”
