Nikon Metrology’s MCAx portable 7-axis arm completes measurement package
1 min read
Nikon Metrology has introduced the MCAx easy-to-use portable 7-axis measuring arm. Its capability, accuracy and repeatability complement the company's ModelMaker MMDx/MMCx digital handheld laser scanners and Focus 10 handheld scanning and inspection software to form a total solution for either the metrology lab, shopfloor or in the field.
The Nikon Metrology MCAx arm features aerospace-grade carbon tubes for stability; absolute encoders for immediate start-up; ergonomic design; and simultaneous probe and scanner mounting. It can be equipped with a wide range of probing systems for laser scanning, touch-trigger measurements and continuous scanning. The range includes 2.0 to 4.5 m diameter measurement volume articulated arms.
ModelMaker MMDx/MMCx digital handheld scanners, paired with MCAx portable articulated co-ordinate measuring arms and fully featured Focus point cloud processing software, can reduce measurement times and allow rapid diagnosis of dimensional quality issues in all areas of manufacturing.
Through Enhanced Scanning Performance (ESP3), the ModelMaker scanner adapts its laser power to suit the surface characteristics of the object. During scanning, it automatically tracks changes in surface conditions – both colour and reflectivity – and adapts laser power and sensor settings accordingly in real time. As a result, ModelMaker is able to handle parts with any surface colour and texture, without requiring re-scanning, spraying or time consuming tuning of scanning parameters.
