Latest hyperCAD version introduces numerous enhancements

One of improvements in the latest version of hyperCAD is that the properties of work planes and references systems can be configured using a shortcut menu. Users also have a considerable amount of freedom with the configuration and appearance of the work planes, allowing them to adapt these according to their individual needs. A completely revised layer management also provides more clarity. It can be activated in the browser’s taskbar and is always available. The status of each layer can be discerned at a glance: name, colours, line type and thickness, number of elements or the status - whether the layer is locked or unlocked, for example. Additional password protection prevents unauthorised access to critical data. Improvements have also been made for simple 3D surfaces and solid functions. New functions, such as ‘rotational extrusion’ or ‘triple tangential rounding’ have been implemented in hyperCAD® 2008.1, which makes modelling even easier for the user. A completely revised graphic interface brings significant advantages when working thanks to improved element representation.
