Entry-level version of ArtCAM software

Delcam’s entry-level version within its ArtCAM family, ArtCAM Express, is aimed at skilled artisans rather than engineers and requires little knowledge of engineering or computing. It is believed to be the easiest to learn and the fastest to use engraving and routing software currently available. ArtCAM Express offers 2D drawing, and 2D and basic 3D machining functions, and so provides an ideal introduction to computer-based manufacturing for companies in the signmaking, woodworking and engraving industries. Designs can be imported in DXF, DWG, AI and EPS 2D formats, while the 3D formats supported include STL files from any CAD system, plus designs from Alias Wavefront, 3D Studio and other members of the ArtCAM family. Once the design has been finalised, the software offers a variety of strategies for CNC machining. 2D strategies supported include area clearance, profiling, engraving, vector-based machining and drilling, plus V-bit carving on all standard Windows fonts. In addition, a 3D raster toolpath can be created within a vector boundary. The software is supplied with a tooling database, which can be edited or added to by the user, plus drivers for many of the leading CNC engraving and routing machines.
