Based on new Apodius 3D technology, this combined hardware and software application package offers advanced inspection and analysis of lightweight carbon fibre components at “an unprecedented level of speed and detail”.
The system comprises HP-C-V3D Apodius Vision Sensor camera-based scanning hardware – designed to fit simply to a Romer Absolute Arm with Integrated Scanner – combined with the custom-built Apodius Explorer 3D real-time software package. It is compatible with all Romer Absolute Arm SI models.
Together, these deliver high definition fibre orientation and geometry measurement and complete 3D model creation and analysis, allowing for actual-to-target value comparison and the capacity to detect, document and classify previously difficult-to-define composite production errors.
Combined with the Romer Absolute Arm SI, which acts as a global reference system for the data collected by the sensor, the Composite Inspection System represents an unmatched solution for the inspection of carbon-fibre components.
Says Alexander Leutner, managing director of Apodius: “The experience and measurement expertise of Hexagon has allowed us to successfully develop a new dimension of flexibility for composite inspection. Until now, three-dimensional digitisation has required the sensor to be robot-mounted. With the technology of the Romer Absolute Arm, we’ve been able to deliver portable hand-guided composite inspection for the first time, resulting in a much faster and more convenient digitisation process.”
Adds Stephan Amann, business director for portable measuring arms at Hexagon Manufacturing Intelligence:“We’re really excited about this new inspection solution for composite component producers. New applications for carbon fibre are emerging all the time. Technology like the Composite Inspection System, which brings the established strengths of the Romer Absolute Arm range together with the sensor and software expertise of Apodius, can drive that growth even further. What we’re looking at this as a collaboration that’s produced an unmatched quality assurance solution that’s exactly what the sector needs to keep growing.”
