Vero Software says that PartXplore 2017 R1 contains many features usually found in high-end CAD systems that enable to the user to perform part diagnostics, create assembly instructions and prepare the production of 3D models. The software, which can open the native files of Edgecam, VISI and WorkNC, was created to import and analyse all file types and sizes at high speed. It often takes less than half the time to open a file, compared to the original CAD application.
The main newly developed items of functionality for PartXplore 2017 R1’s translators are:
3D PDF support for mesh writing
JTOpen support for mesh writing
Reader and writer support for MEG files
It is now possible to write solid and mesh models into the 3D PDF and JTOpen formats, and the resulting files will contain mesh entities. Solid and mesh models can also be exported in the MEG format used by Edgecam.
