Delcam's 2012 version of its integrated CAM system for SolidWorks includes programming of 2D wire EDM for the first time together with comprehensive options for the programming of turning, mill-turn, drilling and 2 to 5-axis milling. Four-axis wire functionality is planned for Delcam for SolidWorks 2012 R2, due for release in January 2012.
Other enhancements include target-part comparison – the ability to compare a model of the desired final shape with the shape achieved by the programmed toolpaths – and multiple-instance programming, the programming of multiple SolidWorks components in one operation, either in the same orientation or in different orientations.
Fully-automated de-burring and chamfering has also been added to give faster programming of these finishing operations on 2 or 2.5-axis parts. The ability to incorporate chamfers, even when they are not shown in the original SolidWorks model, duplicates functionality previously available in Delcam's feature-based CAM system, FeatureCAM.
Delcam for SolidWorks 2012 also incorporates enhancements from the 2012 release of FeatureCAM, including improvements in the use of stock models and new options in the tooling database. Stock models allow the user to visualise the material remaining after each operation. This makes it easier to eliminate air cutting and so generate more efficient toolpaths with reduced machining times. The models also simplify the selection of the most appropriate tool sizes for rest-roughing and finishing operations.
The tooling database is a key part of the automation in Delcam for SolidWorks as it allows the optimum operating conditions to be associated with each tool.
