Quality system measures and verifies 3D features

The SMAC XYZ system is a quality check (QC) development that measures and verifies three dimensional features, using modified SMAC actuators and multiple actuator assemblies for a multi-axis control solution. Any SMAC actuator can be combined into one system: slide, linear, and rotary/linear units. Specific arrangements of the units deliver the capability to learn and follow a particular 3D contour or motion path. Complex programming is not required as the user can simply manually ‘trace’ the 3D path required by the actuators; it is then automatically stored in the controller's memory. Alternatively a comparative check can be made using a reference part. The system also features and utilises linear interpolation that enables a constant speed while following the chosen XYZ axis contour.
